Fordetails,refertotheinstructionsin“ThinkPadEdgeE420specialkeys”onpage27.
ThinkPadEdgeE520frontview
Figure2.ThinkPadEdgeE520frontview
1UltraConnectwirelessantennas(left)
2Integratedhighsensitivitywebcam
3Built-inmicrophone
4UltraConnectwirelessantennas(right)
5Numerickeypad6Powerswitch
7Fingerprintreader
8System-statusindicators(illuminatedThinkPadlogo)
9Built-instereospeaker(right)
10Bluetoothantenna
11TrackPointpointingstick12TrackPointbuttons
13Touchpadbuttons14Touchpad
15Built-instereospeaker(left)
16Volumecontrolbuttons
1UltraConnectwirelessLAN/WiMAXantennasandwirelessWANantennas(left)
4UltraConnectwirelessLAN/WiMAXantennasandwirelessWANantennas(right)
Thebuilt-inantennasforthewirelesscommunicationarelocatedatthetopleftandtoprightportionsof
yourcomputerdisplay.
Fordetails,refertotheinstructionsin“LocationoftheUltraConnectwirelessantennas”onpage164
.
2Integratedhighsensitivitywebcam
Yourcomputermayhaveanintegratedhighsensitivitywebcam.Byusingthiscamera,youcantakepictures
orholdavideoconference.
