3USB3.0connector
TheUSB3.0connectorisusedforconnectingdevicescompatiblewithaUSBinterface,suchasaUSB
printeroradigitalcamera.
Notes:
•WhenyouattachaUSBcabletotheconnector,ensurethattheUSBmarkisfacingupward.Otherwise
theconnectormightbedamaged.
•TheUSB3.0functiononlyworksintheWindows7operatingsystem.IfyouareusingotherWindows
operatingsystemratherthanWindows7,theconnectorworksasaUSB2.0connector.
4Ethernetconnector
ConnectyourcomputertoaLANwiththeEthernetconnector.
DANGER
Toavoidtheriskofelectricalshock,donotconnectthetelephonecabletotheEthernetconnector.
YoucanonlyconnectanEthernetcabletothisconnector.
Therearetwoindicatorstoshowthestatusofthenetworkconnection,onelocatedtotheupperrightof
theconnectorandtheothertotheupperleft.WhenyourcomputerconnectstoaLANandasessionwith
thenetworkisavailable,theupperleftindicatorissteadygreen.Whiledataisbeingtransmitted,theupper
rightindicatorblinksyellow.
5Fanlouver
Theinternalfanandlouversenableairtocirculateinthecomputerandcoolthecentralprocessor.
Note:Toavoidimpedingairow,donotplaceanyobstacleinfrontofthefan.
6Securitykeyhole
Purchaseasecuritycablelockthattsthiskeyholetolockyourcomputertoastationaryobjecttoprotect
yourcomputerfromtheft.
Chapter1.Productoverview5
