In step 2, lift the MG frame a little in the direction shown by the arrow, and then
remove it in the direction shown by arrow 3.
Attention: Before step 2, be sure that the Ultrabay Slim device eject lever is not
popped out and it is housed in its position properly as shown in the figure a.
2
3
a
Removing and replacing a FRU
90 MT 8747, 8749, 9440, 9441, 9442, 9443, and 9448
