•“InstallingaPCIecardonthesystemboard”onpage92
Adjustingthecard-retainingbracket
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage63.
Note:ThistopicapplieswhenthelengthofthePCIecardtobeinstallediseitherofthefollowing:
•176.4mm(6.94inches)
•From185mm(7.28inches)to220mm(8.66inches)
Toadjustthecard-retainingbracket,dothefollowing:
1.Removethethreescrewsthatsecurethecard-retainingbracket.Then,movethecard-retainingbracket
tothedirectionasshown.
Figure52.Removingthescrewstoadjustthecard-retainingbracket
2.Dooneofthefollowing:
Chapter6.Replacinghardware87
