Figure2.Labelonservermodelswith2.5-inch-drivebays
Frontviewoftheserver
Thefrontviewoftheservervariesbymodel.Theillustrationsinthistopicshowtheserverfrontviews
basedonthesupportedinternaldrives:
“Frontviewofservermodelswith3.5-inchdrives”onpage17
“Frontviewofservermodelswith2.5-inchdrives”onpage18
“Frontviewofservermodelswith2.5-inchdrivesandaslimopticaldrive”onpage19
“Frontviewofservermodelswithaninternaltapedrive”onpage20
Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
Frontviewofservermodelswith3.5-inchdrives
0
1 3
2
5
4
7
6
Figure3.Frontviewofservermodelswith3.5-inchdrives
1Rackhandle(left)
2Frontpanel
3Pull-outinformationcard
4Slimopticaldrive(availableonsomemodels)
53.5-inch-drivebays(0–7)6Rackhandle(right)
Chapter3.Productoverview17
