Lenovo ThinkServer RD450 - Rear View of the Server

4SystemIDbuttonwithIDLED
WhenyoupresstheIDbuttononthefrontpanel,theIDLEDsonboththefrontandrearoftheserverare
littohelpyoulocatetheserveramongotherservers.YoualsocanturnontheIDLEDsusingaremote
managementprogramforserverpresencedetection.
StatusColor
Description
On
Blue
Theserverisidentified.
Off
None
TheIDLEDisnotinuseortheserverisnotidentified.
5FrontUSB2.0connectors(2)
UsedtoattachaUSB-compatibledevice,suchasaUSBkeyboard,mouse,scanner,orprinter.Ifyou
havemorethansixUSBdevices,youcanpurchaseaUSBhub,whichyoucanusetoconnectadditional
USBdevices.
6VGAconnector
UsedtoattachaVGA-compatiblevideodevice,suchasaVGAmonitor.
Rearviewoftheserver
Thistopicprovidesinformationtohelpyoulocatetheconnectorsandcomponentsontherearofyourserver.












Figure8.Rearviewoftheserver
1Powersupply1
2Powersupply2(availableonsomemodels)
3PCIeslot64PCIeslot3(onrisercardassembly2)
5PCIeslot4(onrisercardassembly2)6PCIeslot5(onrisercardassembly2)
7PCIeslot1(onrisercardassembly1)8PCIeslot2(onrisercardassembly1)
9SystemIDLED10USB3.0connectors(2)
11Ethernetconnector2(RJ-45)12Ethernetconnector1(RJ-45)
13Serialconnector14Ethernetconnectorforsystemmanagement(RJ-45)
15VGAconnector
Chapter3.Productoverview23
