FRUdescription
Self-serviceCRUOptional-serviceCRU
LenovoThinkServerSystemManagerPremium
module*
YesNo
LenovoThinkServerTrustedPlatformModule*
YesNo
MemorymoduleYesNo
MicroprocessorNoYes
Opticaldrive*
YesNo
Opticalmodule*
YesNo
PCIecard*
YesNo
PCIesolid-statedrive*
YesNo
Powercord*YesNo
RisercardYesNo
Securedigital(SD)card*
YesNo
SDmodule*
NoYes
Systemboard
NoNo
Systemfan
YesNo
Systemfancage
YesNo
AnyRAIDadapterandRAIDcard
ThistopicprovidesinformationabouttheconnectorsontheAnyRAIDadapterandRAIDcard.Youcan
purchaseasupportedAnyRAIDadapterandRAIDcardfromLenovoandinstallitintotheserver.Foralistof
ThinkServeroptions,goto:
http://lenovoquickpick.com/usa/home/thinkserver/rack-and-tower-server
Note:TheoptionkitforAnyRAIDadapterorRAIDcardisdesignedfordifferenttypesofserversandmight
containadditionalcablesthatarenotrequiredforyourserver.
YouserveralsosupportstheHostBusAdapter.TheHostBusAdapterisusedtoconnectyourserverto
externalstoragedevices,suchasastoragearray.
YourserversupportsthefollowingAnyRAIDadaptersandRAIDcards:
AnyRAIDadapters(supportedtypevariesbyservermodel):
•LenovoThinkServerRAID110iAnyRAIDAdapter(alsocalledpass-throughboard)
•LenovoThinkServerRAID510iAnyRAIDAdapter
•LenovoThinkServerRAID720iAnyRAIDAdapter
•LenovoThinkServerRAID720ixAnyRAIDAdapter
RAIDcard:
•LenovoThinkServerRAID500PCIeAdapter
•LenovoThinkServerRAID520iPCIeAdapter
•LenovoThinkServerRAID710PCIeAdapter
•LenovoThinkServerRAID720iPCIeAdapter
ThefollowingillustrationshelpyoulocatetheconnectorsontheAnyRAIDadaptersandRAIDcards.
