Note:Dependingontheconfiguration,theAnyRAIDadapterorRAIDcardinstalledinyourservermightlook
slightlydifferentfromtheillustrationsinthistopic.
LenovoThinkServerRAID110iAnyRAIDAdapter
TheLenovoThinkServerRAID110iAnyRAIDAdapterprovidesSATAsoftwareRAIDfunction.Thefollowing
illustrationshowstheconnectorsontheadapter.
Figure11.LenovoThinkServerRAID110iAnyRAIDAdapter
1SATA0–3connector
UsedtoconnecttotheSATAconnector0(ports0–3)onthesystemboard.See“Systemboardcomponents”
onpage41.
2SATA4–7connector
UsedtoconnecttotheSATAconnector1(ports4–7)onthesystemboard.See“Systemboardcomponents”
onpage41.
Chapter3.Productoverview29
