LenovoThinkServerRAID510iAnyRAIDAdapter
TheLenovoThinkServerRAID510iAnyRAIDAdapterprovidesadvancedSATA/SAShardwareRAID
functions.Thefollowingillustrationshowstheconnectorsontheadapter.
Figure12.LenovoThinkServerRAID510iAnyRAIDAdapter
1PCIE0connector
2PCIE1connector
UsedtoconnecttotheAnyRAIDconnector0–1onthesystemboard.See“Systemboardcomponents”
onpage41.
3RAIDupgradekeyconnector
UsedtoconnectaThinkServerRAID510iupgradekey.
30ThinkServerRD450UserGuideandHardwareMaintenanceManual
