LenovoThinkServerRAID720iAnyRAIDAdapter
TheLenovoThinkServerRAID720iAnyRAIDAdapterprovidesadvancedSATA/SAShardwareRAID
functions.Thefollowingillustrationshowstheconnectorsontheadapter.
Figure13.ThinkServerRAID720iAnyRAIDAdapter
1ThinkServerRAIDSuperCapacitorModuleconnector(availableonsomemodels)
UsedtoconnecttotheThinkServerRAIDSuperCapacitorModule.See“Servercomponents”onpage25
.
2PCIE0connector
3PCIE1connector
UsedtoconnecttotheAnyRAIDconnector0–1onthesystemboard.See“Systemboardcomponents”
onpage41.
Chapter3.Productoverview31
