Systemboardcomponents
Thefollowingillustrationshowsthecomponentlocationsonthesystemboard.
Figure27.Systemboardcomponents
1SATAconnector(opticaldrive)2Coin-cellbattery
3SATAconnector1(ports4–7)4Storage-drivepowerconnector
5AnyRAIDconnector0–1
6SATAconnector0(ports0–3)
7Frontpanelconnector18Frontpanelconnector2
9SDmoduleconnector
10Risercardassembly1slot
11TSMPremiumconnector
12TPMconnector
13PCIeslot
14Risercardassembly2slot
15RAIDupgradekeyconnector16Powersupplyconnector2
17Powersupplyconnector118Intrusionswitchconnector
19Backplanepowerconnector220Backplanepowerconnector1
21Microprocessor2memoryslots(4)22Systemfan5connector
23Microprocessor2socket
24Systemfan4connector
25Microprocessor2memoryslots(4)26Microprocessor1memoryslots(4)
27Systemfan2connector
28Microprocessor1socket
29Systemfan1connector30Microprocessor1memoryslots(4)
1SATAconnector(opticaldrive)
Usedtoconnectthesignalcableoftheslimopticaldrive.
Chapter3.Productoverview41
