Backplaneforuptoeight2.5-inchdrives(withmini-SASconnectors)
Thefollowingillustrationsshowtheconnectorsonthebackplaneforuptoeight2.5-inchdrives(with
mini-SASconnectorsontherear).
Figure25.Frontview
Figure26.Rearview
0–7Slot0–slot7
Usedtoconnect2.5-inchhot-swapdrives.
910-pinpowerconnector
Usedtoconnectapowercabletoprovidepowertothebackplane.
810Mini-SASconnectors
Usedtoconnectthemini-SASconnectorsonaRAIDadapter.YoualsocanuseaSATAtomini-SASsignal
cabletoconnectthebackplanetotheSATAconnectorsonthesystemboard.
40ThinkServerRD450UserGuideandHardwareMaintenanceManual
