Backplaneforuptoeight2.5-inchdrives(withanAnyRAID-adapterslot)
Thefollowingillustrationsshowtheslotsandconnectorsonthebackplaneforuptoeight2.5-inchdrives.
0 1 2 3 4 5 6 7
Figure23.Frontviewofthebackplaneforuptoeight2.5-inchdrives
8 9
10
11
Figure24.Rearviewofthebackplaneforuptoeight2.5-inchdrives
0–7Slot0–slot7
Usedtoconnect2.5-inchdrives.
810-pinpowerconnector0
Usedtoconnecttothe10-pinbackplanepowerconnectoronthesystemboardtoprovidepowertothe
backplane.
9AnyRAIDadapterslot0
UsedtoconnectanAnyRAIDadapter.
104-pinpowerconnector
Usedtoconnecttoaninternaltapedriveifoneisinstalled.
112-pinpowerconnector
Usedtoconnecttoaslimopticaldriveifoneisinstalled.
