Backplaneforuptosixteen2.5-inchdrives
Thefollowingillustrationsshowtheslotsandconnectorsonthebackplaneforuptosixteen2.5-inchdrives.
0 1 2 3 4 5 6 7 8 9 1210 11 13 14 15
Figure21.Frontviewofthebackplaneforuptosixteen2.5-inchdrives
16 17
Figure22.Rearviewofthebackplaneforuptosixteen2.5-inchdrives
0–15Slot0–slot15
Usedtoconnect2.5-inchdrives.
1610-pinpowerconnector0
Usedtoconnecttothe10-pinbackplanepowerconnectoronthesystemboardtoprovidepowertothe
backplane.
17AnyRAIDadapterslot0
UsedtoconnectanAnyRAIDadapter.
