2Coin-cellbattery
Yourserverhasaspecialtypeofmemorythatmaintainsthedate,time,andconfigurationinformationfor
built-infeatures.Thecoin-cellbatterykeepstheinformationactivewhenyouturnofftheserver.
3SATAconnector1(ports4–7)
Usedtoconnecttooneofthefollowingconnectors:
•SASconnector2(ports4–7)onthebackplaneforuptoeight3.5-inchdrives
•SATA4–7connectorontheLenovoThinkServerRAID110iAnyRAIDAdapter
•SATAconnector(ports4–7)ontheeasy-swap-drivemodule
4Storage-drivepowerconnector
Usedtoconnectthe4-pinpowerconnectorontheeasy-swap-drivemodule.
5AnyRAIDconnector0–1
UsedtoconnecttothePCIeconnectorsontheAnyRAIDadapter.
6SATAconnector0(ports0–3)
Usedtoconnecttooneofthefollowingconnectors:
•SASconnector1(ports0–3)onthebackplaneforuptoeight3.5-inchdrives
•SATA0–3connectorontheLenovoThinkServerRAID110iAnyRAIDAdapter
•SATAconnector(ports0–3)ontheeasy-swap-drivemodule
7Frontpanelconnector1
Usedtoconnecttothefrontpanelboard.
8Frontpanelconnector2
UsedtoconnecttothefrontVGAandUSBmodule.
9SDmoduleconnector
UsedtoconnectanSDmodule.
10Risercardassembly1slot
Usedtoinstalltherisercardassembly1.
11TSMPremiumconnector
UsedtoconnectaTSMpremiummoduletoenableadvancedremotemanagementfunctionsonyourserver.
12TPMconnector
UsedtoconnectaTPM.TPMisasecuritychipthatisusedtoenhanceserversecurity.
