2Frontpanel
Forinformationaboutthecontrols,connectors,andstatusLEDsonthefrontpanel,see“Frontpanel”
onpage21.
3Pull-outinformationcard
Themachinetype,model,andserialnumberlabeloftheserverisattachedonthepull-outinformationcard.
See“Machinetype,model,andserialnumberlabel”onpage16.
42.5-inch-drivebays(0–23)
TheEMIintegrityandcoolingoftheserverareprotectedbyhavingalldrivebayscoveredoroccupied.
Thenumberoftheinstalleddrivesinyourservervariesbymodel.Thevacantdrivebaysareoccupied
bydummytrays.
Whenyouinstalldrives,followtheorderofthedrivebaynumbers.
Dependingonyourservermodel,allorsomeofthedrive-baygroups,suchasbays0–7,bays8–15,and
bays16–23,mightbecoveredbyEMI-protectivepanelsasawhole.
Frontviewofservermodelswith2.5-inchdrivesandaslimopticaldrive
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Figure5.Frontviewofservermodelswith2.5-inchdrivesandaslimopticaldrive
1Rackhandle(left)
2Frontpanel
3Pull-outinformationcard
42.5-inch-drivebays(0–15)
5Slimopticaldrive(availableonsomemodels)6Rackhandle(right)
16Rackhandles
Ifyourserverisinstalledinarackcabinet,youcanusetherackhandlestohelpyouslidetheserveroutof
therackcabinet.Youalsocanusetherackhandlesandscrewstosecuretheserverintherackcabinetso
thattheservercannotslideout,especiallyinvibration-proneareas.Formoreinformation,refertotheRack
InstallationInstructionsthatcomeswithyourserver.
2Frontpanel
Forinformationaboutthecontrols,connectors,andstatusLEDsonthefrontpanel,see“Frontpanel”
onpage21.
3Pull-outinformationcard
Themachinetype,model,andserialnumberlabeloftheserverisattachedonthepull-outinformationcard.
See“Machinetype,model,andserialnumberlabel”onpage16
.
Chapter3.Productoverview19
