•Dependingonthespecifictype,yourAnyRAIDadapterandtheAnyRAIDflashmodulemightlookdifferent
fromtheillustrationinthistopic.
ToinstalltheAnyRAIDflashmodule,dothefollowing:
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
2.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage65.
3.Removetheservercover.See“Removingtheservercover”onpage65.
4.LocatetheAnyRAIDadapter.See“Servercomponents”onpage25.
5.Removeanypartsanddisconnectanycablesthatmightimpedeyouroperation.
6.PositiontheAnyRAIDflashmoduleabovetheAnyRAIDadapterandalignthetwoholesintheAnyRAID
flashmodulewiththetwopinsontheAnyRAIDadapter.Then,lowertheAnyRAIDflashmodulestraight
downuntilitissecurelyseated.
Note:Ifnecessary,removetheAnyRAIDadapterfirstforeasieroperation.Then,reinstalltheAnyRAID
adapter.See“ReplacingtheAnyRAIDadapter”onpage98
.
Figure70.InstallingtheAnyRAIDflashmodule
7.Reinstallanypartsandreconnectanycablesthatyouhaveremoved.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage178.
RemovingtheAnyRAIDflashmodule
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage63.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:Dependingonthespecifictype,yourAnyRAIDadapterandtheAnyRAIDflashmodulemightlook
differentfromtheillustrationinthistopic.
ToremovetheAnyRAIDflashmodule,dothefollowing:
Chapter6.Replacinghardware101
