InstallingtheRAID510ikey
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage63.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:UseanydocumentationthatcomeswiththeRAID510ikeyandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
ToinstalltheRAID510ikey,dothefollowing:
Attention:InstallingtheupgradekeymightimpactyourRAIDconfigurations.Backupyourdatabefore
youbegintoavoidanydatalossduetoaRAIDconfigurationchange.
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
2.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage65.
3.Removetheservercover.See“Removingtheservercover”onpage65.
4.LocatetheLenovoThinkServerRAID510iAnyRAIDAdapter.See“Servercomponents”onpage25.
5.Touchthestatic-protectivepackagethatcontainstheRAID510ikeytoanyunpaintedsurfaceonthe
outsideoftheserver.Then,taketheRAID510ikeyoutofthepackage.
Note:CarefullyhandletheRAID510ikeybyitsedges.
6.LocatetheconnectorfortheRAID510ikeyontheLenovoThinkServerRAID510iAnyRAIDAdapter.
Then,inserttheRAID510ikeyintotheconnector.EnsurethattheRAID510ikeyissecurelyseatedon
theAnyRAIDadapter.
Note:Ifnecessary,removetheLenovoThinkServerRAID510iAnyRAIDAdapterfirstforeasier
operation.Then,reinstalltheLenovoThinkServerRAID510iAnyRAIDAdapter.See“Replacingthe
AnyRAIDadapter”onpage98
.
Figure74.InstallingtheRAID510ikey
Whattodonext:
Chapter6.Replacinghardware105
