Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•Youmustturnofftheserverbeforeinstallingorreplacinganeasy-swapdrivetoavoiddatalost.
•Useanydocumentationthatcomeswiththedriveandfollowthoseinstructionsinadditiontothe
instructionsinthistopic.
Toinstallorreplaceaneasy-swapstoragedrive,dothefollowing:
1.Reviewthefollowinginstallationrules:
•Whenyouinstalldrives,followtheorderofthedrivebaynumbers.See“Frontviewoftheserver”on
page17
tolocatethedrivebaysinyourserver.
•ForRAIDconfiguration,thedrivesmustbethesametypewiththesamecapacityiftheyarewithina
singleRAIDarray.Formoreinformation,see“ConfiguringRAID”onpage58.
2.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
3.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage65.
4.Locatetheappropriateeasy-swap-drivebay.See“Frontviewoftheserver”onpage17.
5.Useascrewdrivertoturnthehandlelock1totheunlockedposition.Thehandleopensautomatically.
1
Figure115.Openingthehandleoftheeasy-swapdriveorthedummytray
6.Pullthehandleandcarefullyslidetheeasy-swapdriveorthedummytrayoutofthefrontofthechassis.
Figure116.Removingtheeasy-swapdriveorthedummytray
Chapter6.Replacinghardware141
