Lenovo ThinkStation C20 - Locating Parts and Connectors on the System Board

Figure3.Componentlocations
1Memorymodules
7Harddiskdrives(3)
2Heatsinkandfanassembly2
8Powersupplyassembly
3Opticaldrivebracket9PCIcard
4Opticaldrive
10Heatsinkandfanassembly1
5Frontfanassemblybracket
11Rearfanassemblies(2)
6Harddiskdrivebay
Locatingpartsandconnectorsonthesystemboard
Note:Yourcomputercomeswithoneofthefollowingsystemboards.
Figure4“Systemboardpartandconnectorlocations”onpage10
showsthelocationsofthepartsand
connectorsononetypeofsystemboard.
Chapter1.Productoverview9
