Lenovo ThinkStation C20 User Manual

Thissectionprovidesinstructionsonhowtoinstallanewharddiskdriveintoyourcomputer.
Toinstallanewharddiskdrive,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandthecomputer.Then,disconnect
allpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtothecomputer.
2.Removethecomputercover.See“Removingthecomputercover”onpage13.
3.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage14.
4.RemovethePCIcardholder.See“RemovingandreinstallingthePCIcardholder”onpage15.
5.Pullthehandleofaspareharddiskdrivebracketouttoremovethebracketfromtheharddiskdrivebay.
6.Toinstallanewharddiskdriveintothebracket,exthesidesofthebracketproperlyandalignpin1,
pin2,pin3,andpin4onthebracketwiththecorrespondingholesintheharddiskdrive.Donot
touchthecircuitboard5ontheharddiskdrive.
Figure18.Installinganewharddiskdriveintothebracket
7.Connectoneendofthesignalcablethatcomeswiththenewharddiskdrivetotherearofthenew
harddiskdrive.
Note:ThesignalcablewillbedifferentdependingonwhetheryouareinstallingaSATAharddisk
driveoraSASharddiskdrive.
Figure19.ConnectingthesignalcabletoaSATAharddiskdrive
24ThinkStationUserGuide

Lenovo ThinkStation C20 Specifications

General

HDD capacity	500 GB
Internal memory	8 GB
Memory clock speed	1333 MHz
Processor cache	12 MB
Processor frequency	2.4 GHz
Processor front side bus	1066 MHz
Power supply	800 W
Plug and Play	Yes

Weight and Dimensions

Depth	444 mm
Width	130 mm
Height	427 mm
