Features and specifications
Dimensions
• Width: 145.0 mm (5.7 inches)
• Height: 366.0 mm (14.4 inches)
• Depth: 293.2 mm (11.5 inches)
Weight (without the package) Maximum configuration as shipped: 6.9 kg (15.1 lb)
Hardware configuration
1. Right-click the Start button to open the Start context menu.
2. Click Device Manager. Type the administrator password or provide
confirmation if prompted.
Power supply 180-watt automatic voltage-sensing power supply
Storage device
• 3.5-inch storage drive
• 2.5-inch storage drive
• M.2 solid-state drive
Video features
The integrated graphics card supports the following:
• HDMI 1.4 out connector
• VGA-out connector
Audio features
• The integrated audio card supports the following:
– Audio line-in connector
– Audio line-out connector
– Headphone connector
– Microphone connector
• The optional discrete audio card provides an enhanced audio experience and
extended capabilities.
Input/Output (I/O) features
• Audio connectors (audio line-in, audio line-out, headphone, and microphone)
• Card reader slot*
• Display connectors (HDMI 1.4 out and VGA-out)
• Ethernet connector
• Serial connector
• USB connector
Expansion
• Card reader*
• Memory slot
• Optical drive*
• PCI Express x1 card slot
• PCI Express x16 graphics card slot
• Storage drive bay
Network features
• Bluetooth*
• Ethernet LAN
• Wireless LAN*
* for selected models
6
Lenovo V55t-15API User Guide
