Information SET-01 17
DIGITAL plus
5.2.3 Multi-Unit Consist (MU)
The LH100 implements smart consisting. Smart consisting allows
you to set up a number of locomotives that can be operated as a
single unit. As many as 256 locomotives can be controlled at the
same time using a common consist address, which we call the
locomotive's multi-unit consist address (MU-address). To you it is
as if you only controlled one single locomotive, but all the
locomotives in the MU react at the same time.
With the LH100 you can (depending on the software version of the
command station you are using) control, assemble and
disassemble multi-unit consists.
Detailed information is found in "Multi-unit consists (MU)" starting on
page (ðp.37 ).
5.2.4 Throwing turnouts and setting signals
Using your LH100 you can throw turnouts, set signals or activate
relays. To allow control via the LH100, these devices must be
connected to accessory decoders LS100/110/120 of
Digital plus by Lenz
®
system or other compatible modules. The
procedure is controlling these devices using the LH100 is described
in "Throwing turnouts and setting signals" starting on page
(ðp.43 ).
5.2.5 Display feedback information
The LH100 can also be used to display the status of the inputs
generated by feedback encoders LR100/101. These feedback
encoders can be used for example to display occupancy of selected
locations of your layout.
You find the directions for displaying feedback information in
"Displaying feedback" starting on page (ðp.46 ).
