Function library
Free connection of analog signals
7−67
L
EDB82MV752 EN 5.2
) Note!
l The process data output words CAN−OUT1.W1/FIF−OUT.W1, CAN−OUT2.W1 and
FIF−OUT.W2 can also be assigned to C0417 and C0418 with 16 bit status
information each:
– With digital configuration under C0417 or C0418 no simultaneous analog
assignment with C0421 (C0421/x = 255)!
– With analog configuration under C0421 no simultaneous digital assignment with
C0417 and C0418 (C0417/x = 255, C0418/x = 255)!
– Otherwise the output signal would be incorrect.
l The process data input words CAN−IN1.W1/FIF−IN.W1, CAN−IN1.W2/FIF−IN.W2,
CAN−IN2.W1 and CAN−IN2.W2 can be defined as analog word or digital word (16
bit). If you link them with analog process data output words (C0421/x = 50, 51 or
60, 61), they must be defined as analog input words. Otherwise the output signal
would be incorrect.
