Lenze E82MV152_4B

Function library
Display of operating data, diagnostics
7−87
L
EDB82MV752 EN 5.2
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0051* Output frequency
with slip
compensation
(MCTRL1−NOUT
+SLIP) or
act. process
controller value
(PCTRL1−ACT)
−650.00 {0.02 Hz} 650.00 The value set will be lost when
switching the mains!
Operation without process controller
(C0238 = 2):
 Display only: Output frequency with slip
compensation (MCTRL1−NOUT+SLIP)
Operation with process controller
(C0238 = 0, 1):
 Selection, if C0412/5 = FIXED−FREE (not
assigned)
 Display if C0412/5 is linked with a signal
source
 7−54
C0052* Motor voltage
(MCTRL1−VOLT)
0 {V} 1000 Only display
C0053* DC−bus voltage
(MCTRL1−DCVOLT)
0 {V} 1000 Only display
C0054* Apparent motor
current
(MCTRL1−IMOT)
0.0 {A} 2000.0 Only display
C0056* Controller load
(MCTRL1−MOUT)
−255 {%} 255 Only display
Under C0311 you can change the display
value for the operating modes vector
control or sensorless torque control.
C0061* Heatsink
temperature
0 {°C} 255 Only display
 If the heatsink temperature is > 
max
−
5 °C:
– The warning
OH will be sent.
– The chopper frequency will be
reduced to 4 kHz, if C0144 = 1
 If the heatsink temperature is > 
max
:
– Controller sets TRIP
OH
C0138* Process controller
setpoint 1
(PCTRL1−SET1)
0.00 −650.00 {0.02 Hz} 650.00 The value set will be lost when
switching the mains!
 Selection if C0412/4 = FIXED−FREE
 Display if C0412/4  FIXED−FREE
 7−53
C0189*
(A)
Output signal
compensator
(PCTRL1−FOLL1−OU
T)
−650.00 {0.02 Hz} 650.00 Only display
Compensator = PCTRL1−FOLL1
C0320
(A)
Actual process
controller value
(PCTRL1−ACT)
−650.00 {0.02 Hz} 650.00 Only display
C0321
(A)
Process controller
setpoint
(PCTRL1−SET)
−650.00 {0.02 Hz} 650.00 Only display
C0322
(A)
Process controller
output without
precontrol
(PCTRL1−OUT)
−650.00 {0.02 Hz} 650.00 Only display
C0323
(A)
Ramp function
generator input
(NSET1−RFG1−IN)
−650.00 {0.02 Hz} 650.00 Only display
C0324
(A)
Ramp function
generator output
(NSET1−NOUT)
−650.00 {0.02 Hz} 650.00 Only display
C0325
(A)
PID controller
output
(PCTRL1−PID−OUT)
−650.00 {0.02 Hz} 650.00 Only display
C0326
(A)
Process controller
output
(PCTRL1−NOUT)
−650.00 {0.02 Hz} 650.00 Only display
