Appendix
Code table
14−50
L
EDB82MV752 EN 5.2
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0517*
User menu
After mains switching or when using the
function
the code from C0517/1
will be displayed.
In Lenze setting, the user menu contains
the most important codes for starting−up
the control mode "V/f characteristic
control with linear characteristic"
When the password protection is
activated, only the codes entered under
C0517 are freely accessible.
Enter the required code numbers in the
subcodes.
Codes, which are only active when
being used together with an
A
lication−I/O
cannot be entered!
7−95
1 Memory 1 50 C0050 Output frequency (MCTRL1−NOUT)
2 Memory 2 34 C0034 Analog setpoint selection range
3 Memory 3 7 C0007 Fixed configuration − digital input signals
4 Memory 4 10 C0010 Minimum output frequency
5 Memory 5 11 C0011 Maximum output frequency
6 Memory 6 12 C0012 Acceleration time main setpoint
7 Memory 7 13 C0013 Deceleration time main setpoint
8 Memory 8 15 C0015 V/f rated frequency
9 Memory 9 16 C0016 U
min
boost
10 Memory 10 2 C0002 Parameter set transfer
C0518
Service codes Modifications only by Lenze Service!
C0519
C0520
C0597*
Configuration of
motor phase failure
detection −28−
0
0 not active
1 TRIP fault message Keypad: LP1, bus: 32
2 Warning Keypad: LP1, bus: 182
C0599*
Current limit value
for motor phase
failure detection
5 1 {1 %} 50 Threshold for C0597
Reference: Rated controller current
C0608* Fan monitoring 0
0 Not active
8200 motec 3 ... 7.5 kW:
Function must be activated during
commissioning (recommended: C0608 = 1)!
Otherwise, the controller may be destroyed
through overheating.
For all other controllers:
It is essential to set C0608 = 0.
1 TRIP error message
2 Warning
C0625* Skip frequency 1 0.00 0.00 {0.02 Hz} 650.00
7−17
C0626* Skip frequency 2 0.00 0.00 {0.02 Hz} 650.00
C0627* Skip frequency 3 0.00 0.00 {0.02 Hz} 650.00
C0628* Bandwidth of skip
frequencies
0.00 0.00 {0.01 %} 100.00 Applies to C0625, C0626, C0627
C0988* DC−bus voltage
threshold for
DC−bus voltage
control
0 0
Parameter set
changeover via
DC−bus voltage
deactivated
{1 %} 200 Changeover always between PAR1 nd
PAR2
Parameter set changeover is not
possible via terminal, bus or PC if
C988 > 0!
C1500*
(A)
Software number
application I/O
82SAFA0B_xy000 Only PC display
x = main version
y = subversion
C1501*
(A)
Software creation
date application I/O
Only PC display
C1502*
(A)
Software ID
application I/O
Output in keypad as string in four parts at four characters
each
Read only in keypad
x = main version
y = subversion
1 82SA
2 FA0B
3 _xy0
4 00
C1504
(A)
Service codes
application I/O
Modifications only by Lenze Service!
...
C1507
(A)
C1550
(A)
Service code
application I/O
Modifications only by Lenze Service!
