Typical values for C0015
400 V E82xVxxxK4 controller 230 V E82xVxxxK2 controller
motor C0015 motor C0015
Voltage Frequency Connection Voltage Frequency Connection
230/400V 50Hz
*
50Hz 230/400V 50Hz + 50Hz
220/380V 50Hz
*
52.6Hz 220/380V 50Hz + 52.3Hz
280/480V 60Hz
*
50Hz
400/690V
400V
50Hz
50Hz
+
50Hz
230/400V
280/480V
400 V
50Hz
60Hz
87 Hz
+
87Hz
220/380V 50Hz
+
90.9Hz
) Note!
l 4−pole asynchronous motors which are designed for a rated frequency of 50Hz
in star connection, can be operated in delta connection if the constant
excitement does not exceed 87Hz.
– The motor current and the motor power increase by the factor 3=1.73.
– The field−weakening range starts above 87Hz.
l Advantages:
– Higher speed−setting range
– 73% higher power output with standard motors.
l In principle, this method can also be used for motors with other pole numbers.
– Observe the mechanical limit speed when using 2−pole asynchronous motors.
