Lenze E82ZAFVC010 - Protective Insulation

Technical data
Protective insulation
4
l
16
EDS82ZAFVCxxx EN 4.0
4.3 Protective insulation
{ Danger!
Dangerous electrical voltage
If Lenze controllers are used on a phase earthed mains with a rated mains
voltage ³ 400 V, protection against accidental contact is not ensured without
implementing external measures.
Possible consequences:
ƒ Death or serious injury
Protective measures:
ƒ If protection against accidental contact is required for the control terminals
of the controller and the connections of the plugged device modules, ...
– a double isolating distance must exist.
– the components to be connected must be provided with the second
isolating distance.
E82ZAFVC001
function module
Protective insulation between bus and ... Type of insulation (acc. to EN 61800−5−1)
l reference earth / PE (X3/SH) Functional insulation
l external supply (X3/V+) No electrical isolation
l supply for CINH (X3/20) No electrical isolation
l controller inhibit, CINH (X3/28) Functional insulation
l power section
– 8200 vector Reinforced insulation
– 8200 motec Reinforced insulation
– starttec Reinforced insulation
l control terminals
– 8200 vector Functional insulation
– 8200 motec Functional insulation
E82ZAFVC010
function module
Protective insulation between bus and ... Type of insulation
l Reference earth / PE (X3.1/SH) Functional insulation
l External supply (X3.1/V+) No functional insulation
l Supply for CINH (X3.2/20) No functional insulation
l Controller inhibit, CINH (X3.2/28) Functional insulation
l 8200 vectorpower unit Double insulation
l 8200 vector control terminals Functional insulation
