Technical data
Connection terminals
4
l
17
EDS82ZAFVCxxx EN 4.0
4.4 Connection terminals
E82ZAFVC001
function module
X3/
V+
External DC voltage supply of the function module:
+24 V DC ±10 %, max. 80 mA
The current flowing via terminal V+ during looping through of the
supply voltage to other devices, is to amount to a maximum of 3 A.
7 Reference potential 1
39 Reference potential 2 of the controller inhibit (CINH) at X3/28
28 Controller inhibit
l Start = HIGH (+12 V ... +30 V)
l Stop = LOW (0 V ... +3 V)
Input resistance: 3.3kW
20 + 20 V internal for CINH, reference potential 1, load capacity: I
max
=
30 mA
E82ZAFVC010
function module
X3.1/
V+
External DC voltage supply of the function module:
+24 V DC ±10 %, max. 80 mA
The current flowing via terminal V+ during looping through of the
supply voltage to other devices, is to amount to a maximum of 3 A.
X3.2/
7
Reference potential 1
39 Reference potential 2 of controller inhibit (CINH) at X3.2/28
28 Controller inhibit
l Start = HIGH (+12 V ... +30 V)
l Stop = LOW (0 V ... +3 V)
Input resistance: 3.3kW
20 + 20 V internal for CINH, reference potential 1, load capacity: I
max
=
30 mA
