Technical data
General data
4
l
15
EDS82ZAFVCxxx EN 4.0
4 Technical data
4.1 General data
Field Values
Communication profile DeviceNet
Communication medium DIN ISO 11898
Network topology Line terminated at both ends (R = 120 Ohms)
Max. number of devices 63
DeviceNet device Slave
Baud rate [kbit/s] 125, 250, 500
Achievable bus cable length Depending on the cable used, see ^ 28
External voltage supply See^ 24
4.2 Operating conditions
Ambient conditions
Climate
Storage
IEC/EN 60721−3−1 1K3 (−25 to +60 °C)
Transport IEC/EN 60721−3−2 2K3 (−25 to +70 °C)
Operation Corresponding to the data of the Lenze standard device used (see documentation
of the standard device).
Pollution EN 61800−5−1 Degree of pollution 2
Degree of protection IP20 (protection against accidental contact according to NEMA 250 type 1)
