Installation
Electrical installation
Wiring with a host (master)
5
l
22
EDS82ZAFVCxxx EN 4.0
Properties of the "Thick Cable" in accordance with DeviceNet specification
General features
Structure Two shielded balanced lines, common axis with drain wire in the centre
Total shielding 65% coverage
AWG 36 (at least 0.12 mm) of tin−coated copper braid (individually tinned)
Drain wire At least copper 18; at least 19 cores (individually tinned)
Outer diameter 10.41 ... 12.45 mm
Concentricity The radius deviation has to be within 15 % of half the outside diameter.
Cable sheath labelling Name of vendor, part no., and additional labelling
Spec. DC resistance (braid, wrapping, leakage) 5.74 W/km (nom. up to 20 °C)
Certifications (U.S. and Canada) NEC (UL), CL2/CL3 (min.)
Bend radius 20 x diameter (installation) / 7 x diameter (fixed)
Ambient temperature (operation) −20 ... +60 °C at 8 amperes;
linear current derating to zero at 80 °C
Storage temperature −40 ... +85 °C
Pull tension 845.5 N
max
Features of the data line
Conductor pair At least copper 18; at least 19 cores (individually tinned)
Insulation diameter 3.81 mm (nom.)
Colours Light blue, white
Pair windings / m Approx. 10
Shielding/conductor pair 2000/1000, Al/Mylar, Al side on the outside, w/shorting fold (for tensile load)
Impedance 120 W +/− 10 % at 1 MHz
Capacitance between conductors 39.37 pF/m at 1 kHz (nom.)
Capacitance between one conductor and another which is
connected to the shield.
78.74 pF/m at 1 kHz (nom.)
Capacitive assymetry 3937 pF/km at 1 kHz (nom.)
Spec. DC resistance at 20 °C 22.64 W/km (max.)
Damping 0.43 dB/100 m at 125 kHz (max.)
0.82 dB/100 m at 500 kHz (max.)
1.31 dB/100 m at 1.00 MHz (max.)
Features of the voltage line
Conductor pair At least copper 15; at least 19 cores (individually tinned)
Insulation diameter 2.49 mm (nom.)
Colours Red / black
Pair windings / m Approx. 10
Shielding/conductor pair 1000/1000, Al/Mylar, Al side on the outside, with w/shorting fold (for tensile load)
Spec. DC resistance at 20 °C 11.81 W/km (max.)
Properties of the "Thin Cable" in accordance with DeviceNet specification
General features
Structure Two shielded balanced lines, common axis with drain wire in the centre
Total shielding 65% coverage
AWG 36 (at least 0.12 mm) of tin−coated copper braid (individually tinned)
Drain wire At least copper 22; at least 19 cores (individually tinned)
Outer diameter 6.096 ... 7.112 mm
Concentricity The radius deviation has to be within 20 % of half the outside diameter.
Cable sheath labelling Name of vendor, part no., and additional labelling
Spec. DC resistance (braid, wrapping, leakage) 10.5 W/km (nom. at 20 °C)
Certifications (U.S. and Canada) NEC (UL), CL2 (min.)
Bend radius 20 x diameter (installation) / 7 x diameter (fixed)
Ambient temperature (operation) −20 ... +70 °C at 1.5 amperes;
linear current derating to zero at 80 °C
Storage temperature −40 ... +85°C
Pull tension 289.23 N
max
