Appendix
Data transfer
Overview of the implemented objects for the function module
9
l
65
EDS82ZAFVCxxx EN 4.0
Manufacturer−specific class 104 (68
hex
)
Instance 0:
Attribute Service(s) Description Data type Value
1 GET Revision UINT 0001
hex
Instance 1:
Attribute Service(s) Description Data type Value
1 GET/SET I/O image of the
received data
(output data of
the scanner)
Array of UINT Value according to the words set
Services:
Service code Name Description
0E
hex
Get_Attribute_Single Reading of an attribute
10
hex
Set_Attribute_Single Writing of an attribute
Manufacturer−specific class 110 (6E
hex
):
access to Lenze codes
Instance (Lenze code):
Attribute Service(s) Description Data type Value
Lenze subcode GET / SET Access to Lenze
code (6E
hex
)
Data type of the
Lenze code
Value of the Lenze code/subcode
) Note!
ƒ If the corresponding Lenze code does not have a subcode, the value "1"
must be entered into the attribute.
ƒ The display code cannot be configured by the "SET" service.
