System modules
AIF1_IO_AutomationInterface (node number 41)
Inputs_AIF1
13
263
EDBCSXA064 EN 3.2
Codes
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
C0136 Control words
Hexadecimal value is bit−coded.
Read only
1 CTRLWORD
0 {hex} FFFF
Control word C0135
2 CTRLWORD CAN control word
3 CTRLWORD AIF control word
C0855 Digital process data input words
are indicated on the AIF interface
(AIF1_IN)
Hexadecimal value is bit−coded.
Read only
259
1 AIF1 IN bits 0000 {hex} FFFF Input word 2 (bit 0 ... 15)
2 AIF1 IN bits Input word 3 (bit 0 ... 15)
C0856 Analog process data input words
are indicated decimally on the
AIF interface (AIF1_IN)
100.00% = 16384
Read only
259
1 AIF1 IN words −199.99 {0.01 %} 199.99 Input word 1
2 AIF1 IN words Input word 2
3 AIF1 IN words Input word 3
C0857 AIF1 IN phi
32 bits of phase information on
the AIF interface (AIF1_IN)
Read only
259
−2147483648 {1} 2147483647
