Appendix
Overview of accessories
14
463
EDBCSXA064 EN 3.2
Brake resistors of type ERBS...
Brake resistors with an increased power loss in IP65 design (NEMA 250 type 4x)
Rated data
Type
Brake resistor
ERBS039R01K6
ERBS020R03K2
Resistance
R
B
[
Ω
]
39
20
Continuous power
P
d
[W]
1640
3200
Amount of heat
Q
B
[kWs]
246
480
Max. running time
t
e
[s]
15
Required recovery time
t
a
[s]
135
Operating voltage
U
max
[V
DC
]
800
Max. braking power
P
Bmax
[kW]
P
Bmax
+
WärmemengeQ
B
Einschaltzeit
462
464
