Commissioning
Setting of the feedback system for position and speed control
Absolute value encoder as position and speed encoder
6

125
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
[C0427] Enc. signal 0
Function of the master frequency
input signals on X8 (DFIN)
 113
 121
0 2−phase
1 A: speed
B: direction
2 A or B: speed or direction
[C0491] X8 in/out 0
Function of X8
 113
 121
0 X8 is input
1 X8 is output
C3000 MotDirInv 0
Motor mounting position
 121
0 Motor mounting position not inverted
1 Motor mounting position inverted
C3001 EncDirInv 0
Encoder mounting position
 113
 121
0 Normal (direction of rotation CW)
Direction of rotation with regard
to motor direction of rotation
1 Inverse (direction of rotation CCW)
