Commissioning
Setting of the feedback system for position and speed control
Absolute value encoder as position and speed encoder
6
124
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
[C0095] Rotor pos adj 0
Activation of rotor position
adjustment for automatic
determination of the rotor
displacement angle.
C0058 displays the determined
rotor displacement angle (offset
angle).
180
0 Inactive
1 Active
[C0419] Enc. setup 110
Encoder selection
l Selection of encoder type
indicated on the nameplate of
the Lenze motor.
l The encoder data (C0420,
C0421, C0427) is set
automatically in accordance
with the selection.
113
121
0 Common
110 IT512−5V
Incremental encoder with TTL
level
111 IT1024−5V
112 IT2048−5V
113 IT4096−5V
210 IS512−5V
SinCos encoder
211 IS1024−5V
212 IS2048−5V
213 IS4096−5V
307 AS64−8V
SinCos absolute value encoder
with Hiperface® interface
(single−turn)
Selections 307, 308, 309 are only
possible with operating system
7.0 or higher.
308 AS128−8V
309 AS256−8V
310 AS512−8V
311 AS1024−8V
407 AM64−8V
SinCos absolute value encoder
with Hiperface® interface
(multi−turn)
Selections 407, 408, 409 are only
possible with operating system
7.0 or higher.
408 AM128−8V
409 AM256−8V
410 AM512−8V
411 AM1024−8V
[C0420] Encoder const. 512
Number of increments of the
encoder
113
121
1 {1 inc/rev} 8192 Sets C0419 = 0 ("common") if the
value is altered.
[C0421] Encoder volt 0
Encoder voltage
113
121
0 5.0 V
Sets C0419 = 0 ("common") if the
value is altered.
1 5.6 V
2 6.3 V
3 6.9 V
4 7.5 V
5 8.1 V
