Lenze ECSEM Series

Appendix
Code table
12

297
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0360 Telegram counter
CAN_IN/CAN_OUT (CAN bus
interface X4), number of
telegrams
Read only
 215
1 CAN
Messages
0 {1} 65535 All sent telegrams
2 CAN
Messages
With a count value > 65535 the counter restarts
with 0
All received telegrams
3 CAN
Messages
Sent to CAN1_OUT
4 CAN
Messages
Sent to CAN2_OUT
5 CAN
Messages
Sent to CAN3_OUT
6 CAN
Messages
Sent on parameter data
channel 1
7 CAN
Messages
Sent on parameter data
channel 2
8 CAN
Messages
Received from CAN1_IN
9 CAN
Messages
Received from CAN2_IN
10 CAN
Messages
Received from CAN3_IN
11 CAN
Messages
Received from parameter data
channel 1
12 CAN
Messages
Received from parameter data
channel 2
C0361 Detected load
CAN_IN/CAN_OUT (CAN bus
interface X4)
Read only
A faultless operation is only
guaranteed if the total bus load
of all connected nodes amounts
to a value £ 80 %.
 216
1 Load IN/OUT 0 {1 %} 100 All sent telegrams
2 Load IN/OUT All received telegrams
3 Load IN/OUT Sent to CAN1_OUT
4 Load IN/OUT Sent to CAN2_OUT
5 Load IN/OUT Sent to CAN3_OUT
6 Load IN/OUT Sent on parameter data
channel 1
7 Load IN/OUT Sent on parameter data
channel 2
8 Load IN/OUT Received from CAN1_IN
9 Load IN/OUT Received from CAN2_IN
10 Load IN/OUT Received from CAN3_IN
11 Load IN/OUT Received from parameter data
channel 1
12 Load IN/OUT Received from parameter data
channel 2
