Code table
12

300
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
[C0416] Resolver adj. 5
Resolver excitation amplitude
 110
0 100 %
1 80 %
2 68 %
3 58 %
4 50 %
5 45 %
6 40 %
7 37 %
[C0417] Resolver cor. 0
Resolver adjustment
 188
0 Ready
1 Start adjustment
2 Loading default values
[C0418] Test Cur.Ctrl 0
Controller adjustment:
 178
0 Deactivated Deactivate test mode
1 Activated Activate test mode
[C0419] Enc. setup 110
Encoder selection
l Selection of encoder type
indicated on the nameplate of
the Lenze motor.
l The encoder data (C0420,
C0421, C0427) is set
automatically in accordance
with the selection.
 113
 121
0 Common
110 IT512−5V
Incremental encoder with TTL
level
111 IT1024−5V
112 IT2048−5V
113 IT4096−5V
210 IS512−5V
SinCos encoder
211 IS1024−5V
212 IS2048−5V
213 IS4096−5V
307 AS64−8V
SinCos absolute value encoder
with Hiperface® interface
(single−turn)
Selections 307, 308, 309 are only
possible with operating system
7.0 or higher.
308 AS128−8V
309 AS256−8V
310 AS512−8V
311 AS1024−8V
407 AM64−8V
SinCos absolute value encoder
with Hiperface® interface
(multi−turn)
Selections 407, 408, 409 are only
possible with operating system
7.0 or higher.
408 AM128−8V
409 AM256−8V
410 AM512−8V
411 AM1024−8V
[C0420] Encoder const. 512
Number of increments of the
encoder
 113
 121
1 {1 inc/rev} 8192 Sets C0419 = 0 ("common") if the
value is altered.
