Appendix
Code table
12

301
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
[C0421] Encoder volt 0
Encoder voltage
 113
 121
0 5.0 V
Sets C0419 = 0 ("common") if the
value is altered.
1 5.6 V
2 6.3 V
3 6.9 V
4 7.5 V
5 8.1 V
C0426 DIS: In
Signal at DFIN input
Only display
−32767 {1 rpm} 32767
[C0427] Enc. signal 0
Function of the master frequency
input signals on X8 (DFIN)
 113
 121
0 2−phase
1 A: speed
B: direction
2 A or B: speed or direction
C0428 DFIN TP sel. 0
DFIN touch probe signal source
0 Zero pulse of position encoder (C0490) X7/X8
1 Touch probe input TP1 X6/DI1
2 Zero pulse of digital frequency input X8
C0429 TP1 delay 0
DFIN dead time compensation
TP1 (DI1)
−32767 {1 inc} 32767
C0431 DFIN TP Edge 0
DFIN touch probe TP1 edge
(for touch probe via digital input
X6/DI1 (C0428 = 1))
0 Rising edge TP1
1 Falling edge TP1
2 Rising and falling edge TP1
3 Switched off
C0443 DIS: DIGIN
Signal status of the digital inputs
on X6 after consideration of the
polarity set under C0114.
Only display
0 {1} 255
Bit 0 DIGIN1 X6/DI1
 140
Bit 1 DIGIN2 X6/DI2
Bit 2 DIGIN3 X6/DI3
Bit 3 DIGIN4 X6/DI4
Bit 4 DIGIN_safe_standstill X6/SI2
0: Pulse inhibit is active
1: Pulse inhibit is inactive
 70
Bit 5 Free
Bit 6 DIGIN_CInh X6/SI1
0: Controller is inhibited (CINH)
1: Controller is enabled
 70
Bit 7 Free
