Lenze ECSEM Series - Page 302

Appendix
Code table
12

302
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0444 Status of the digital outputs
Only display
1 DIS: DIGOUT 0 1 Status of the digital output
X6/DO1
2 DIS: DIGOUT Relay control status
[C0469] Fct STP key 2
Function of the STOP key of the
keypad
Must not be changed if the
"STOP" key is pressed!
0 Inactive Without function
1 Controller inhibit (CINH)
2 Quick stop (QSP)
C0470 Freely configurable code for
digital signals
Hexadecimal value is bit−coded.
1 FCODE 8bit 0 00 {hex} FF C0470/1 = C0471, bit 0 ... 7
2 FCODE 8bit 0 C0470/2 = C0471, bit 8 ... 15
3 FCODE 8bit 0 C0470/3 = C0471, bit 16 ... 23
4 FCODE 8bit 0 C0470/4 = C0471, bit 24 ... 31
C0471 FCODE 32bit 0
Hexadecimal 32−bit
interpretation of C0470
0 {1} 4294967295
C0472 Freely configurable code for
relative analog signals
1 FCODE analog 0.00 −199.99 {0.01 %} 199.99
2 FCODE analog 0.00
3 FCODE analog 100.00
4 FCODE analog 0.00
... ... ...
10 FCODE analog 0.00
{10.00}
Speed threshold for closing the
holding brake with reference to
the value in C0011 (maximum
speed n
max
).
11 FCODE analog 0.00 Value/direction of the torque
against the holding brake
... ... ...
20 FCODE analog 0.00
C0473 Freely configurable code for
absolute analog signals
1 FCODE abs 1 −32767 {1} 32767
2 FCODE abs 1
3 FCODE abs 0
... ... ...
10 FCODE abs 0
C0474 Freely configurable code for
phase signals
1 FCODE PH 0 −2147483647 {1} 2147483647
... ... ...
5 FCODE PH 0
