Appendix
Code table
12

303
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0475 Freely configurable code for
phase difference signals
1 FCODE DF 0 −16000 {1 rpm} 16000
2 FCODE DF 0
[C0490] Feedback pos 0
Selection of feedback system for
positioning control
 109
0 Resolver at X7 Standard setting
1 TTL encoder at X8
l Sets C0419 = 0 ("Common") if
a different encoder type as
under C0419 is set here.
2 SinCos encoder at X8
3 Absolute value encoder (single−turn) at
X8
4 Absolute value encoder (multi−turn) at
X8
[C0491] X8 in/out 0
Function of X8
 113
 121
0 X8 is input
1 X8 is output
[C0495] Feedback n 0
Selection of feedback system for
speed control
 109
0 Resolver at X7 Standard setting
1 TTL encoder at X8
l Sets C0419 = 0 ("Common") if
a different encoder type as
under C0419 is set here.
2 SinCos encoder at X8
3 Absolute value encoder (single−turn) at
X8
4 Absolute value encoder (multi−turn) at
X8
C0497 Nact filter 2.0
Time constant of actual speed
value
0.0 {0.1 ms} 50.0 0.0 ms = switched off
C0504
Service codes Only the Lenze service is allowed
to make changes!
...
C0509
C0510
ProtAppFlash 0
Write−protection application
FLASH
0 No write protection
1 Write protection is active
C0517 User menu with up to 32 entries
0.00 {0.01} 7999.00 l Enter the numbers of the
required codes into the
subcodes.
Format: xxxx.yy
– xxxx = code number
– yy = subcode of the code
l It is not checked whether the
entered code exists.
1 User menu 51.00 C0051 MCTRL−NACT Display of actual speed
2 User menu 54.00 C0054 Imot Display of motor current
3 User menu 56.00 C0056 MCTRL−MSET2 Display of torque setpoint
4 User menu 0.00 Not assigned
5 User menu 0.00 Not assigned
6 User menu 183.00 C0183 Diagnostics Display for diagnostics
