Code table
12

305
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0559 SD8 filter t 1
Filter time constant (SD8)
1 {1 ms} 200 Example:
If the setting is "10 ms", a
SD8−TRIP is actuated after 10 ms.
C0576 nErr tolerance 100
Tolerance window for the speed
system deviation referring to
n
max
100 % = lowest monitoring
sensitivity
 249
0 {1 %} 100
C0577 Vp fld weak 0.100
Gain of the field weakening
controller (V
p
)
 185
0.000 {0.001} 63.999
C0578 Tn fld weak 3.0
Integral−action time of the field
weakening controller (V
n
)
0.1 {0.1 ms} 6000.0
C0579 nErr response 3
Fault response − monitoring of
speed system deviation
 249
0 TRIP
1 Message
2 Warning
3 Off
4 FAIL−QSP
C0580 Monit SD8 3
Fault response − monitoring of
SinCos signals at X8
 248
0 TRIP
3 Off
C0581 MONIT EEr 0
Fault response − external fault
monitoring "ExternalFault" (EEr)
0 TRIP
1 Message
2 Warning
3 Off
4 FAIL−QSP
C0582 MONIT OH4 2
Setting of the fault response −
monitoring of heatsink
temperature in C0122
 231
0 TRIP
2 Warning
3 Off
C0583 MONIT OH3 0
Fault response − monitoring of
motor temperature (fixed
temperature threshold).
Detection through KTY thermal
sensor via resolver input X7 or
encoder input X8.
 229
0 TRIP
2 Warning
3 Off
