Appendix
Code table
12

306
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0584 MONIT OH7 2
Fault response − motor
temperature monitoring
Temperature threshold can be
set under C0121.
Detection through KTY thermal
sensor via resolver input X7 or
encoder input X8.
Only effective if OH3 is switched
on under C0583.
 229
0 TRIP
2 Warning
3 Off
C0586 MONIT SD2 0
Fault response − monitoring
Resolver "ResolverFault" (Sd2)
 245
0 TRIP
2 Warning
3 Off
C0588 MONIT
H10/H11
0
Fault response − monitoring
Thermal sensors in the
controller.
H10: Sensor inside the device
H11: Heatsink sensor
 233
0 TRIP
2 Warning
3 Off
C0591 MONIT CE1 3
Fault response − monitoring
CAN1_IN (no telegrams)
"CommErrCANIN1" (CE1)
 225
0 TRIP
2 Warning
3 Off
C0592 MONIT CE2 3
Fault response − monitoring
CAN2_IN (no telegrams)
"CommErrCANIN2" (CE2)
 225
0 TRIP
2 Warning
3 Off
C0593 MONIT CE3 3
Fault response − monitoring
CAN3_IN (no telegrams)
"CommErrCANIN3" (CE3)
 225
0 TRIP
2 Warning
3 Off
C0594 MONIT SD6 3
Fault response − monitoring
KTY sensor for the motor
temperature.
"SensorFault" (Sd6)
 246
0 TRIP
2 Warning
3 Off
