Appendix
Code table
12

307
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0595 MONIT CE4 3
Fault response − system bus
(CAN) monitoring "Bus−off" at X4
"BusOffState" (CE4)
 225
0 TRIP
2 Warning
3 Off
C0596 NMAX limit 5500
Maximum system speed
 250
0 {1 rpm} 16000
C0597 MONIT LP1 3
Fault response − monitoring of
motor phase failure (LP1)
When this function is activated,
the calculating time provided for
the user program is reduced!
 244
0 TRIP
2 Warning
3 Off
C0598 MONIT SD5 3
Fault response − master current
monitoring at X6 < 2 mA
"MastISourceDef"
0 TRIP
2 Warning
3 Off
C0599 Limit LP1 5.0
Monitoring limit for motor phase
failure monitoring (LP1) with
regard to the current limit.
 244
0.01 {0.01 %} 10.00
C0602 MONIT REL1 3
Fault response − open circuit
monitoring of relay output X25
0 TRIP
2 Message
3 Off
4 FAIL−QSP
C0603 MONIT CE5 3
Fault response − gateway
function monitoring (CE5)
"Timeout" when remote
parameter setting (C0370) is
activated via interface X4 (CAN)
 225
 217
0 TRIP
2 Warning
3 Off
C0604 MONIT OC7 2
Fault response − monitoring of
Ixt device utilisation.
Ixt threshold can be set under
C0123.
 228
0 TRIP
2 Warning
3 Off
