Appendix
Code table
12
308
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0605 MONIT OH5 2
Fault response − monitoring of
temperature inside the
controller.
Temperature threshold can be
set under C0124.
232
0 TRIP
2 Warning
3 Off
C0606 MONIT OC8 2
Fault response − monitoring of
I
2
x t motor utilisation.
Threshold can be set under
C0120.
237
0 TRIP
2 Warning
3 Off
C0607 MONIT NMAX 0
Fault response − maximum speed
monitoring of the machine
0 TRIP
2 Warning
3 Off
C0608 ovr. Tx−Queue 2
Fault response − transmission
memory overflow of free CAN
objects
0 TRIP
1 Message
2 Warning
3 Off
4 FAIL−QSP
C0609 ovr. Rx−Isr 0
Fault response Receive memory
overflow of free CAN objects
0 TRIP
4 FAIL−QSP
C0651
Delay T 0.006
{1.000}
DT1−1 time constant
−0.005 {0.001 s} 199.999
C0653 Sensibility 1
DT1−1 sensitivity
1 15 bits
2 14 Bit
3 13 bits
4 12 bits
5 11 bits
6 10 bits
7 9 bits
C0855 Digital process data input words
are indicated on the AIF interface
(AIF1_IN)
Hexadecimal value is bit−coded.
Read only
1 AIF1 IN bits 0000 {hex} FFFF Input word 2 (bit 0 ... 15)
2 AIF1 IN bits Input word 3 (bit 0 ... 15)
