Code table
12

312
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0909 speed limit 1
Limitation of direction of
rotation for speed setpoint
1 −175 ... +175 %
2 0 ... +175 %
3 −175 ... 0 %
C0910 MCTRL TP2
delay
0
MCTRL dead time compensation
TP2 (X6/DI2)
−32767 {1 inc} 32767 1 inc º approx. 60 ms
C0911 MCTRL TP2
sel.
0
MCTRL touch probe signal source
0 Zero pulse of position encoder (C0490) X7/X8
1 Touch probe input TP2 X6/DI2
C0912 MCTRL TP2
Edge
0
MCTRL touch probe TP2 edge
(for touch probe via digital input
X6/DI2 (C0911 = 1))
0 Rising edge TP2
1 Falling edge TP2
2 Rising and falling edge TP2
3 Switched off
C0935 L_REF1 speed 100 Traversing speed of homing
 143
1 {1 rpm} 16000
C0936 L_REF1 Ti 1.0 Deceleration time (T
i
) of homing
 143
0.01 {0.01 s} 650.00
C1120 Sync mode 0
{1}
Sync signal source
 207
0 Off Off
1 CAN sync Sync connection via interface X4
(CAN)
 210
2 Terminal sync Sync connection via terminal
X6/DI1
 211
C1121 Sync cycle 2
Synchronisation cycle
 207
1 {1 ms} 13
C1122 Sync phase 0.460
Synchronisation phase
 207
0.000 {0.001 ms} 6.500
C1123 Sync window 0.010
Synchronisation window
l If the sync telegram/signal
sent by the master is inside
this "time slot", C3165 is set
to 1.
 209
0.000 {0.001 ms} 6.500
