Appendix
Code table
12

313
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C1190 MPTC mode 0
Selection of PTC motor
temperature sensor
characteristic
0 Characteristic for PTC 83−110 (Lenze
standard)
1 Can be specifically set by the user
under C1191 and C1192
2 Characteristic for PTC 83−110 and 2 x
PTC150 (e.g. in MCS motors)
This selection is only available as
of operating system V 8.0. For
the corresponding motors, the
parameter is not automatically
transferred into GDC by the
motor data assistant. The
parameter has to be set later!
C1191 Selection of temperature
characteristic for PTC
1 Char.: temp 25 0 {1 °C} 255 PTC characteristic:
lower temperature T1
2 Char.: temp 150 PTC characteristic:
upper temperature T2
C1192 Selection of resistance
characteristic for PTC
1 Char.: OHM 1000
{0}
0 {1 W} 30000 PTC characteristic:
resistance R1 at T1
2 Char.: OHM 2225 PTC characteristic:
resistance R2 at T2
C1810 SW ID LECOM Software identification LECOM
Only display
C1811 SW date
LECOM
Software creation date LECOM
Only display
C2100 Time slice 13
Time slice for cyclic task
6 {1 ms} 26
C2102 Task switch 0
Change−over:
System task àcycl. task (PLC)
0 Time slice No change−over
1 Time slice + end of PLC_PRG
2 Time slice + end of PLC_PRG + end of
system task
C2104 PLC Autorun 0
{1}
Automatic start of PLC program
after power−up
0 Off
1 On
C2106 Downl.protect 0
Write protection of PLC program
0 Inactive
1 Active
2 Reserved
C2108 PLC run/stop 0
Control PLC program
0 No function
1 Run
2 Stop
3 Reset
