IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C2111 GDC Id 27012006132510 =
l Date (day.month.year): 27.01.2006
l Time (h:min:sec): 13:25:10
Creation date of PLC program
Read only
C2113 PLC Prog
Name
Name of PLC program
Read only
C2115 T−Fkt Credit 0 Number of technology units
C2116 CreditPinCode 0
Code for technology units if
service is required (please
consult Lenze)
0 {1} 4294967295
C2117 Full Credit 0 Service code
C2118 ParWriteChan
.
0
CAN object for L_ParRead and
L_ParWrite
(byComChannel = 10)
 217
0 Unused PDO channel free for
reconfiguration
(CAN1...3_IN/CAN1...3_OUT)
1 Parameter data channel 2
C2120 AIF: Control 0
AIF−CAN: control word
0 {1} 255 Binary interpretation reflects bit
states
0 No command
Note: The MSB (bit 7) of the
control word automatically
changes its state with every
access to the code. Observe this
when interpreting the data!
1 Read XCAN codes + reinitialisation
2 Read XCAN code
10 Read XCAN C2356/1 ... 4
11 Read XCAN C2357
12 Read XCAN C2375
13 Read XCAN C2376 ... C2378
14 Read XCAN C2382
255 Not assigned
C2121 AIF:State
AIF status
More detailed information can
be found in the documentation
of the plugged−in fieldbus
module.
Read only
1 {1} 255 Binary interpretation reflects bit
states.
Bit 0 XCAN1_IN monitoring time
Bit 1 XCAN2_IN monitoring time
Bit2 XCAN3_IN monitoring time
Bit3 XCAN bus off
Bit4 XCAN operational
Bit5 XCAN pre−operational
Bit 6 XCAN warning
Bit 7 Assigned internally
