Code table
12

315
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C2130 FileNameAdd
Da
Symbolic data name
Information on the additional
data that have been transmitted
together with the application
program.
Only display
C2131 Type AddData Specification identification of the data
C2132 VersionAddDa
ta
Data version
C2133 TimeStamp Time stamp of the data
C2350 XCAN address 1
Node address XCAN
(AIF interface X1)
1 {1} 63
C2351 XCAN baud
rate
0
Baud rate XCAN
(AIF interface X1)
0 500 kbps
1 250 kbit/sec
2 125 kbits/s
3 50 kbps
4 1000 kbit/s
C2352 XCAN mst 0
Establish XCAN master
operation.
(AIF interface X1)
0 Slave
1 Master
C2353 Source for system bus node
addresses of
XCAN_IN/XCAN_OUT
(AIF interface X1)
1 XCAN addr sel 0 CAN node address (C2350) XCAN1_IN/OUTaddress
2 XCAN addr sel 0 CAN node address (C2350) XCAN2_IN/OUTaddress
3 XCAN addr sel 0 CAN node address (C2350) XCAN3_IN/OUTaddress
0 C2350 (auto) Automatically determined by
C2350
1 C2354 (man.) Determined by C2354
C2354 Alternative node addresses for
XCAN_IN/XCAN_OUT
(AIF interface X1)
1 XCAN addr. 129 1 {1} 512 XCAN1_INaddress 2
2 XCAN addr. 1 XCAN1_OUTaddress 2
3 XCAN addr. 257 XCAN2_INaddress 2
4 XCAN addr. 258 XCAN2_OUTaddress 2
5 XCAN addr. 385 XCAN3_INaddress 2
6 XCAN addr. 386 XCAN3_OUTaddress 2
C2355 Identifier for
XCAN_IN/XCAN_OUT
(AIF interface X1)
Read only
1 XCAN Id 1 {1} 2047 Identifier XCAN1_IN
2 XCAN Id Identifier XCAN1_OUT
3 XCAN Id Identifier XCAN2_IN
4 XCAN Id Identifier XCAN2_OUT
5 XCAN Id Identifier XCAN3_IN
6 XCAN Id Identifier XCAN3_OUT
