Appendix
Code table
12

317
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C2375 TX mode for XCANx_OUT
(AIF interface X1)
1 XCAN Tx
mode
0 Response to sync XCAN1_OUT
2 XCAN Tx
mode
0 Response to sync XCAN2_OUT
3 XCAN Tx
mode
0 Response to sync XCAN3_OUT
0 Response to sync
1 No response to sync
2 Event
3 Event, cycle C2356 superimposed
C2376 XCAN1_OUT mask
(AIF interface X1)
1 XCAN1 Mask FFFF 0000 {hex} FFFF Mask for process data output
word 1
2 XCAN1 Mask FFFF Mask for process data output
word 2
3 XCAN1 Mask FFFF Mask for process data output
word 3
4 XCAN1 Mask FFFF Mask for process data output
word 4
C2377 XCAN2_OUT mask
(AIF interface X1)
1 XCAN2 Mask FFFF 0000 {hex} FFFF Mask for process data output
word 1
2 XCAN2 Mask FFFF Mask for process data output
word 2
3 XCAN2 Mask FFFF Mask for process data output
word 3
4 XCAN2 Mask FFFF Mask for process data output
word 4
C2378 XCAN3_OUT mask
(AIF interface X1)
1 XCAN3 Mask FFFF 0000 {hex} FFFF Mask for process data output
word 1
2 XCAN3 Mask FFFF Mask for process data output
word 2
3 XCAN3 Mask FFFF Mask for process data output
word 3
4 XCAN3 Mask FFFF Mask for process data output
word 4
